Panamax ITW-MCO4 Analog Station Set and Central Office Line Protector

Features:

• Analog Station Set and Central Office Line Protector
• Protects up to 4-wires (2-pairs) per jack. Using RJ11/45 connectors (2in/2out, pins 3, 6, 4, 5 protected)
• Auto-Resetting Technology: PTC resistors open when a surge occurs, protecting your equipment, but unlike other fuses, the PTCs close again once the surge passes.
• Expandable modular system
• Applications: Analog and Central Office lines for PBX or KSU
• Agency Approval: UL 497A (Secondary)
• Grounding Requirements: Uses Electrical AC Ground
• Recommended Grounding Impedance: <0.5Ohm
• Signal Perfect Circuitry
• Auto-Resetting PTCs: 160 mA (8-10 Ohms)
• Clamping Level: 260V
• Response Time: 1-5 Nanoseconds
• Capacitance: <50pF
• Suppression Modes: Metallic and Longitudinal
• Wires Protected: 4-wires (2-pairs) per jack (pins 3, 6, 4, 5)
• Termination Type: RJ11/45
